How to Install and Configure Nginx as a Reverse Proxy on Linux

A reverse proxy sits between client requests and your backend servers, providing load balancing, SSL termination, caching, and security. Nginx is the most popular choice for this role due to its performance and flexibility. This guide covers installing Nginx and configuring it as a reverse proxy on Ubuntu, Debian, RHEL, and CentOS.

What is a Reverse Proxy?

A reverse proxy accepts requests from clients and forwards them to one or more backend servers. Unlike a forward proxy (which clients use to access the internet), a reverse proxy handles incoming traffic to your infrastructure.

Benefits of using Nginx as a reverse proxy:

• Load balancing – Distribute traffic across multiple backend servers
• SSL termination – Handle HTTPS at the proxy, reducing backend load
• Caching – Cache static content to reduce backend requests
• Security – Hide backend server details and add security headers
• Compression – Compress responses to reduce bandwidth

Installing Nginx

On Ubuntu/Debian

# Update package index
sudo apt update

# Install Nginx
sudo apt install nginx -y

# Start and enable Nginx
sudo systemctl start nginx
sudo systemctl enable nginx

# Verify installation
nginx -v

On RHEL/CentOS/AlmaLinux

# Install EPEL repository (if needed)
sudo dnf install epel-release -y

# Install Nginx
sudo dnf install nginx -y

# Start and enable Nginx
sudo systemctl start nginx
sudo systemctl enable nginx

# Open firewall ports
sudo firewall-cmd --permanent --add-service=http
sudo firewall-cmd --permanent --add-service=https
sudo firewall-cmd --reload

Basic Reverse Proxy Configuration

Let’s configure Nginx to proxy requests to a backend application running on port 3000 (common for Node.js apps).

Step 1: Create Configuration File

# Create a new site configuration
sudo nano /etc/nginx/sites-available/myapp

Step 2: Add Reverse Proxy Configuration

server {
    listen 80;
    server_name example.com www.example.com;

    location / {
        proxy_pass http://localhost:3000;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection 'upgrade';
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_cache_bypass $http_upgrade;
    }
}

Step 3: Enable the Site

# Create symbolic link to enable site
sudo ln -s /etc/nginx/sites-available/myapp /etc/nginx/sites-enabled/

# Test configuration
sudo nginx -t

# Reload Nginx
sudo systemctl reload nginx

Proxy Configuration for Different Applications

Node.js/Express Application

location / {
    proxy_pass http://localhost:3000;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection 'upgrade';
    proxy_set_header Host $host;
    proxy_cache_bypass $http_upgrade;
}

Python Flask/Django Application

location / {
    proxy_pass http://127.0.0.1:8000;
    proxy_set_header Host $host;
    proxy_set_header X-Real-IP $remote_addr;
    proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
}

PHP-FPM with FastCGI

location ~ \.php$ {
    fastcgi_pass unix:/var/run/php/php8.2-fpm.sock;
    fastcgi_index index.php;
    fastcgi_param SCRIPT_FILENAME $document_root$fastcgi_script_name;
    include fastcgi_params;
}

Adding SSL with Let’s Encrypt

Secure your reverse proxy with free SSL certificates from Let’s Encrypt:

# Install Certbot
sudo apt install certbot python3-certbot-nginx -y   # Ubuntu/Debian
sudo dnf install certbot python3-certbot-nginx -y   # RHEL/CentOS

# Obtain and install certificate
sudo certbot --nginx -d example.com -d www.example.com

# Verify auto-renewal
sudo certbot renew --dry-run

After running Certbot, your configuration will be automatically updated with SSL settings:

server {
    listen 443 ssl;
    server_name example.com www.example.com;

    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;
    include /etc/letsencrypt/options-ssl-nginx.conf;
    ssl_dhparam /etc/letsencrypt/ssl-dhparams.pem;

    location / {
        proxy_pass http://localhost:3000;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection 'upgrade';
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
    }
}

server {
    listen 80;
    server_name example.com www.example.com;
    return 301 https://$server_name$request_uri;
}

Load Balancing Multiple Backend Servers

Configure Nginx to distribute traffic across multiple backend servers:

# Define upstream servers
upstream backend_servers {
    least_conn;  # Load balancing method
    server 192.168.1.10:3000 weight=3;
    server 192.168.1.11:3000 weight=2;
    server 192.168.1.12:3000 backup;
}

server {
    listen 80;
    server_name example.com;

    location / {
        proxy_pass http://backend_servers;
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
    }
}

Load balancing methods:

• round-robin (default) – Distributes requests evenly
• least_conn – Sends to server with fewest active connections
• ip_hash – Routes based on client IP (session persistence)
• hash – Custom hash based on specified variable

Caching for Better Performance

Enable caching to reduce backend load:

# Add to http block in nginx.conf
proxy_cache_path /var/cache/nginx levels=1:2 keys_zone=my_cache:10m max_size=1g inactive=60m;

# Add to server block
server {
    listen 80;
    server_name example.com;

    location / {
        proxy_cache my_cache;
        proxy_cache_valid 200 60m;
        proxy_cache_valid 404 1m;
        proxy_cache_use_stale error timeout updating;
        add_header X-Cache-Status $upstream_cache_status;

        proxy_pass http://localhost:3000;
        proxy_set_header Host $host;
    }

    # Bypass cache for dynamic content
    location /api/ {
        proxy_pass http://localhost:3000;
        proxy_no_cache 1;
        proxy_cache_bypass 1;
    }
}

Security Headers

Add security headers to protect your application:

server {
    listen 443 ssl;
    server_name example.com;

    # Security headers
    add_header X-Frame-Options "SAMEORIGIN" always;
    add_header X-Content-Type-Options "nosniff" always;
    add_header X-XSS-Protection "1; mode=block" always;
    add_header Referrer-Policy "strict-origin-when-cross-origin" always;
    add_header Content-Security-Policy "default-src 'self';" always;
    add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;

    # Hide Nginx version
    server_tokens off;

    location / {
        proxy_pass http://localhost:3000;
        # ... other proxy settings
    }
}

WebSocket Support

For applications using WebSockets (real-time apps, chat, etc.):

location /socket.io/ {
    proxy_pass http://localhost:3000;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection "upgrade";
    proxy_set_header Host $host;
    proxy_read_timeout 86400;
}

Rate Limiting

Protect your backend from abuse with rate limiting:

# Add to http block
limit_req_zone $binary_remote_addr zone=api_limit:10m rate=10r/s;

server {
    listen 80;
    server_name example.com;

    location /api/ {
        limit_req zone=api_limit burst=20 nodelay;
        proxy_pass http://localhost:3000;
    }
}

Monitoring and Logging

Configure detailed logging for troubleshooting:

# Custom log format
log_format proxy_log '$remote_addr - $remote_user [$time_local] '
                     '"$request" $status $body_bytes_sent '
                     '"$http_referer" "$http_user_agent" '
                     'upstream: $upstream_addr response_time: $upstream_response_time';

server {
    access_log /var/log/nginx/proxy_access.log proxy_log;
    error_log /var/log/nginx/proxy_error.log warn;

    location / {
        proxy_pass http://localhost:3000;
    }
}

Testing Your Configuration

# Test Nginx configuration syntax
sudo nginx -t

# Reload Nginx (graceful)
sudo systemctl reload nginx

# Check Nginx status
sudo systemctl status nginx

# View error logs
sudo tail -f /var/log/nginx/error.log

# Test reverse proxy
curl -I http://example.com

Troubleshooting Common Issues

502 Bad Gateway

• Backend server not running
• Wrong proxy_pass URL or port
• SELinux blocking connections (RHEL/CentOS)

# Check if backend is running
sudo ss -tlnp | grep 3000

# Fix SELinux (if needed)
sudo setsebool -P httpd_can_network_connect 1

504 Gateway Timeout

• Backend taking too long to respond
• Increase timeout values

proxy_connect_timeout 60;
proxy_send_timeout 60;
proxy_read_timeout 60;

Complete Production Configuration Example

upstream app_servers {
    least_conn;
    server 127.0.0.1:3000;
    keepalive 32;
}

server {
    listen 80;
    server_name example.com www.example.com;
    return 301 https://$server_name$request_uri;
}

server {
    listen 443 ssl http2;
    server_name example.com www.example.com;

    # SSL Configuration
    ssl_certificate /etc/letsencrypt/live/example.com/fullchain.pem;
    ssl_certificate_key /etc/letsencrypt/live/example.com/privkey.pem;
    ssl_protocols TLSv1.2 TLSv1.3;
    ssl_ciphers ECDHE-ECDSA-AES128-GCM-SHA256:ECDHE-RSA-AES128-GCM-SHA256;
    ssl_prefer_server_ciphers off;

    # Security Headers
    add_header X-Frame-Options "SAMEORIGIN" always;
    add_header X-Content-Type-Options "nosniff" always;
    add_header Strict-Transport-Security "max-age=31536000" always;
    server_tokens off;

    # Logging
    access_log /var/log/nginx/example.com.access.log;
    error_log /var/log/nginx/example.com.error.log;

    # Gzip Compression
    gzip on;
    gzip_vary on;
    gzip_min_length 1024;
    gzip_types text/plain text/css application/json application/javascript;

    location / {
        proxy_pass http://app_servers;
        proxy_http_version 1.1;
        proxy_set_header Upgrade $http_upgrade;
        proxy_set_header Connection 'upgrade';
        proxy_set_header Host $host;
        proxy_set_header X-Real-IP $remote_addr;
        proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;
        proxy_set_header X-Forwarded-Proto $scheme;
        proxy_cache_bypass $http_upgrade;
        proxy_read_timeout 90;
    }

    # Static files (optional)
    location /static/ {
        alias /var/www/example.com/static/;
        expires 30d;
        add_header Cache-Control "public, immutable";
    }
}

Conclusion

Nginx as a reverse proxy is essential for modern web infrastructure. It provides load balancing, SSL termination, caching, and security features that protect and optimize your backend applications. Start with a basic configuration and gradually add features like caching and rate limiting as your needs grow.

For high-availability setups, consider combining Nginx with tools like Keepalived for failover, and use monitoring tools like Prometheus with the nginx-exporter to track performance metrics.
