Learn how to use Terraform to provision AWS infrastructure including EC2 instances, VPCs, security groups, and S3 buckets. This hands-on tutorial walks you through real-world examples of managing AWS resources with Infrastructure as Code.

Prerequisites

• Terraform installed (version 1.0+)
• AWS account with programmatic access
• AWS CLI installed and configured
• Basic understanding of AWS services

Setting Up AWS Credentials

Option 1: AWS CLI Configuration

# Configure AWS CLI
aws configure

# Enter your credentials:
AWS Access Key ID: AKIAXXXXXXXXXX
AWS Secret Access Key: xxxxxxxxxxxxxxxxxx
Default region name: us-east-1
Default output format: json

Option 2: Environment Variables

export AWS_ACCESS_KEY_ID="your-access-key"
export AWS_SECRET_ACCESS_KEY="your-secret-key"
export AWS_REGION="us-east-1"

Option 3: Terraform Provider Block

# Not recommended for production - use for testing only
provider "aws" {
  region     = "us-east-1"
  access_key = "your-access-key"
  secret_key = "your-secret-key"
}

Project Structure

aws-terraform-project/
├── main.tf
├── variables.tf
├── outputs.tf
├── providers.tf
├── vpc.tf
├── ec2.tf
├── s3.tf
├── security-groups.tf
└── terraform.tfvars

Provider Configuration

Create providers.tf:

terraform {
  required_version = ">= 1.0"

  required_providers {
    aws = {
      source  = "hashicorp/aws"
      version = "~> 5.0"
    }
  }
}

provider "aws" {
  region = var.aws_region

  default_tags {
    tags = {
      Environment = var.environment
      ManagedBy   = "Terraform"
      Project     = var.project_name
    }
  }
}

Variables Configuration

Create variables.tf:

variable "aws_region" {
  description = "AWS region to deploy resources"
  type        = string
  default     = "us-east-1"
}

variable "environment" {
  description = "Environment name"
  type        = string
  default     = "dev"
}

variable "project_name" {
  description = "Project name for tagging"
  type        = string
  default     = "terraform-demo"
}

variable "vpc_cidr" {
  description = "CIDR block for VPC"
  type        = string
  default     = "10.0.0.0/16"
}

variable "public_subnet_cidrs" {
  description = "CIDR blocks for public subnets"
  type        = list(string)
  default     = ["10.0.1.0/24", "10.0.2.0/24"]
}

variable "private_subnet_cidrs" {
  description = "CIDR blocks for private subnets"
  type        = list(string)
  default     = ["10.0.10.0/24", "10.0.20.0/24"]
}

variable "instance_type" {
  description = "EC2 instance type"
  type        = string
  default     = "t3.micro"
}

variable "key_name" {
  description = "SSH key pair name"
  type        = string
  default     = ""
}

Creating a VPC

Create vpc.tf:

# Get available AZs
data "aws_availability_zones" "available" {
  state = "available"
}

# VPC
resource "aws_vpc" "main" {
  cidr_block           = var.vpc_cidr
  enable_dns_hostnames = true
  enable_dns_support   = true

  tags = {
    Name = "vpc-main"
  }
}

# Internet Gateway
resource "aws_internet_gateway" "main" {
  vpc_id = aws_vpc.main.id

  tags = {
    Name = "igw-main"
  }
}

# Public Subnets
resource "aws_subnet" "public" {
  count                   = length(var.public_subnet_cidrs)
  vpc_id                  = aws_vpc.main.id
  cidr_block              = var.public_subnet_cidrs[count.index]
  availability_zone       = data.aws_availability_zones.available.names[count.index]
  map_public_ip_on_launch = true

  tags = {
    Name = "subnet-public-${count.index + 1}"
    Type = "Public"
  }
}

# Private Subnets
resource "aws_subnet" "private" {
  count             = length(var.private_subnet_cidrs)
  vpc_id            = aws_vpc.main.id
  cidr_block        = var.private_subnet_cidrs[count.index]
  availability_zone = data.aws_availability_zones.available.names[count.index]

  tags = {
    Name = "subnet-private-${count.index + 1}"
    Type = "Private"
  }
}

# Public Route Table
resource "aws_route_table" "public" {
  vpc_id = aws_vpc.main.id

  route {
    cidr_block = "0.0.0.0/0"
    gateway_id = aws_internet_gateway.main.id
  }

  tags = {
    Name = "rt-public"
  }
}

# Associate public subnets with public route table
resource "aws_route_table_association" "public" {
  count          = length(aws_subnet.public)
  subnet_id      = aws_subnet.public[count.index].id
  route_table_id = aws_route_table.public.id
}

Security Groups

Create security-groups.tf:

# Web Server Security Group
resource "aws_security_group" "web" {
  name        = "sg-web-server"
  description = "Security group for web servers"
  vpc_id      = aws_vpc.main.id

  # HTTP
  ingress {
    from_port   = 80
    to_port     = 80
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
    description = "HTTP"
  }

  # HTTPS
  ingress {
    from_port   = 443
    to_port     = 443
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]
    description = "HTTPS"
  }

  # SSH
  ingress {
    from_port   = 22
    to_port     = 22
    protocol    = "tcp"
    cidr_blocks = ["0.0.0.0/0"]  # Restrict in production!
    description = "SSH"
  }

  # All outbound traffic
  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }

  tags = {
    Name = "sg-web-server"
  }
}

# Database Security Group
resource "aws_security_group" "db" {
  name        = "sg-database"
  description = "Security group for databases"
  vpc_id      = aws_vpc.main.id

  # MySQL from web servers only
  ingress {
    from_port       = 3306
    to_port         = 3306
    protocol        = "tcp"
    security_groups = [aws_security_group.web.id]
    description     = "MySQL from web servers"
  }

  egress {
    from_port   = 0
    to_port     = 0
    protocol    = "-1"
    cidr_blocks = ["0.0.0.0/0"]
  }

  tags = {
    Name = "sg-database"
  }
}

EC2 Instances

Create ec2.tf:

# Get latest Amazon Linux 2023 AMI
data "aws_ami" "amazon_linux" {
  most_recent = true
  owners      = ["amazon"]

  filter {
    name   = "name"
    values = ["al2023-ami-*-x86_64"]
  }

  filter {
    name   = "virtualization-type"
    values = ["hvm"]
  }
}

# Get latest Ubuntu 22.04 AMI
data "aws_ami" "ubuntu" {
  most_recent = true
  owners      = ["099720109477"]  # Canonical

  filter {
    name   = "name"
    values = ["ubuntu/images/hvm-ssd/ubuntu-jammy-22.04-amd64-server-*"]
  }
}

# EC2 Instance
resource "aws_instance" "web" {
  ami                    = data.aws_ami.amazon_linux.id
  instance_type          = var.instance_type
  subnet_id              = aws_subnet.public[0].id
  vpc_security_group_ids = [aws_security_group.web.id]
  key_name              = var.key_name != "" ? var.key_name : null

  root_block_device {
    volume_size           = 20
    volume_type           = "gp3"
    encrypted             = true
    delete_on_termination = true
  }

  user_data = <<-EOF
    #!/bin/bash
    yum update -y
    yum install -y httpd
    systemctl start httpd
    systemctl enable httpd
    echo "
Hello from Terraform!
Instance: $(hostname)





📧 Subscribe to Our Newsletter

Get notified when we publish new Linux tutorials and guides!

















                        Subscribe Now
                        Subscribing...








                    We respect your privacy. Unsubscribe anytime.




" > /var/www/html/index.html
  EOF

  tags = {
    Name = "web-server-1"
    Role = "webserver"
  }
}

# Elastic IP for web server
resource "aws_eip" "web" {
  instance = aws_instance.web.id
  domain   = "vpc"

  tags = {
    Name = "eip-web-server"
  }
}

S3 Buckets

Create s3.tf:

# Generate random suffix for unique bucket name
resource "random_id" "bucket_suffix" {
  byte_length = 4
}

# S3 Bucket for static assets
resource "aws_s3_bucket" "assets" {
  bucket = "assets-bucket-${var.environment}-${random_id.bucket_suffix.hex}"

  tags = {
    Name = "Assets Bucket"
  }
}

# Bucket versioning
resource "aws_s3_bucket_versioning" "assets" {
  bucket = aws_s3_bucket.assets.id

  versioning_configuration {
    status = "Enabled"
  }
}

# Bucket encryption
resource "aws_s3_bucket_server_side_encryption_configuration" "assets" {
  bucket = aws_s3_bucket.assets.id

  rule {
    apply_server_side_encryption_by_default {
      sse_algorithm = "AES256"
    }
  }
}

# Block public access
resource "aws_s3_bucket_public_access_block" "assets" {
  bucket = aws_s3_bucket.assets.id

  block_public_acls       = true
  block_public_policy     = true
  ignore_public_acls      = true
  restrict_public_buckets = true
}

# S3 Bucket for logs
resource "aws_s3_bucket" "logs" {
  bucket = "logs-bucket-${var.environment}-${random_id.bucket_suffix.hex}"

  tags = {
    Name = "Logs Bucket"
  }
}

# Lifecycle policy for logs
resource "aws_s3_bucket_lifecycle_configuration" "logs" {
  bucket = aws_s3_bucket.logs.id

  rule {
    id     = "archive-old-logs"
    status = "Enabled"

    transition {
      days          = 30
      storage_class = "STANDARD_IA"
    }

    transition {
      days          = 90
      storage_class = "GLACIER"
    }

    expiration {
      days = 365
    }
  }
}

Outputs

Create outputs.tf:

output "vpc_id" {
  description = "VPC ID"
  value       = aws_vpc.main.id
}

output "public_subnet_ids" {
  description = "Public subnet IDs"
  value       = aws_subnet.public[*].id
}

output "private_subnet_ids" {
  description = "Private subnet IDs"
  value       = aws_subnet.private[*].id
}

output "web_server_public_ip" {
  description = "Public IP of web server"
  value       = aws_eip.web.public_ip
}

output "web_server_public_dns" {
  description = "Public DNS of web server"
  value       = aws_instance.web.public_dns
}

output "assets_bucket_name" {
  description = "Assets S3 bucket name"
  value       = aws_s3_bucket.assets.bucket
}

output "logs_bucket_name" {
  description = "Logs S3 bucket name"
  value       = aws_s3_bucket.logs.bucket
}

Deploying the Infrastructure

# Initialize Terraform
terraform init

# Validate configuration
terraform validate

# Preview changes
terraform plan

# Apply changes
terraform apply

# View outputs
terraform output

Testing Your Infrastructure

# Get the public IP
terraform output web_server_public_ip

# Test web server (wait a minute for user_data to complete)
curl http://$(terraform output -raw web_server_public_ip)

# SSH to instance (if key_name was provided)
ssh -i your-key.pem ec2-user@$(terraform output -raw web_server_public_ip)

Cleaning Up

# Destroy all resources
terraform destroy

# Confirm with yes

Best Practices

• Use variables for values that change between environments
• Enable encryption for S3 buckets and EBS volumes
• Restrict security groups to specific IP ranges in production
• Use remote state for team collaboration
• Tag all resources for cost tracking and organization
• Use data sources for AMIs instead of hardcoding IDs

Conclusion

You have learned how to provision a complete AWS infrastructure using Terraform, including VPC, subnets, security groups, EC2 instances, and S3 buckets. This foundation can be expanded to include RDS databases, load balancers, auto-scaling groups, and more complex architectures.
