Introduction to Kubernetes on Rocky Linux 9
Kubernetes has become the de facto standard for container orchestration in 2026, and Rocky Linux 9 provides an enterprise-grade, stable foundation for production Kubernetes clusters. This comprehensive guide walks you through installing and configuring a complete Kubernetes cluster on Rocky Linux 9, from initial server setup to deploying your first application.
π Table of Contents
- Introduction to Kubernetes on Rocky Linux 9
- Why Rocky Linux 9 for Kubernetes?
- Prerequisites
- Step 1: Initial System Configuration
- Update System Packages
- Set Hostnames
- Configure /etc/hosts
- Disable Swap
- Disable SELinux (Temporary – For Testing)
- Step 2: Install Container Runtime (containerd)
- Load Required Kernel Modules
- Configure Kernel Parameters
- Install containerd
- Configure containerd
- Step 3: Install Kubernetes Components
- Add Kubernetes Repository
- Install Kubernetes Packages
- Step 4: Configure Firewall
- Master Node Firewall Rules
- Worker Node Firewall Rules
- Step 5: Initialize Kubernetes Master Node
- Initialize the Cluster
- Configure kubectl Access
- Verify Master Node Status
- Step 6: Install Pod Network (Flannel)
- Step 7: Join Worker Nodes to Cluster
- Verify Cluster Status
- Step 8: Deploy Test Application
- Create Deployment
- Expose as Service
- Check Deployment Status
- Access the Application
- Step 9: Install Kubernetes Dashboard (Optional)
- Deploy Dashboard
- Create Admin User
- Get Access Token
- Access Dashboard
- Step 10: Monitoring and Management Tools
- Install Metrics Server
- Install Helm Package Manager
- Production Best Practices
- High Availability Configuration
- Security Hardening
- Backup and Disaster Recovery
- Resource Management
- Troubleshooting Common Issues
- Pods Stuck in Pending State
- Node NotReady Status
- Network Issues
- Certificate Expiration
- Upgrading Kubernetes on Rocky Linux 9
- Upgrade Master Node
- Upgrade Worker Nodes
- Cost Optimization for Kubernetes
- Next Steps
- Conclusion
Whether you’re building a development environment or deploying production workloads, this tutorial covers everything you need to know about running Kubernetes on Rocky Linux 9.
Why Rocky Linux 9 for Kubernetes?
Rocky Linux 9 is an excellent choice for Kubernetes deployments:
- Enterprise stability: 100% RHEL-compatible with 10-year support lifecycle
- Security: SELinux enabled by default, regular security updates
- Cost-effective: Free alternative to RHEL with no licensing fees
- Community support: Large enterprise user base and active community
- Compatibility: Works seamlessly with commercial Kubernetes platforms (OpenShift, Rancher)
Prerequisites
Before starting, ensure you have:
- Rocky Linux 9: Fresh installation with minimal package set
- Hardware requirements:
- Master node: 2 CPU cores, 4GB RAM, 20GB disk minimum
- Worker nodes: 2 CPU cores, 2GB RAM, 20GB disk minimum
- Network: Static IP addresses for all nodes, internet connectivity
- Root or sudo access: Administrative privileges required
- Firewall ports: See firewall configuration section below
This guide assumes a 3-node cluster: 1 master (control plane) and 2 worker nodes.
Step 1: Initial System Configuration
Perform these steps on ALL nodes (master and workers).
Update System Packages
sudo dnf update -y
sudo dnf install -y vim wget curlSet Hostnames
Set unique hostnames for each node:
# On master node
sudo hostnamectl set-hostname k8s-master
# On worker node 1
sudo hostnamectl set-hostname k8s-worker1
# On worker node 2
sudo hostnamectl set-hostname k8s-worker2Configure /etc/hosts
Add entries for all cluster nodes on EACH machine:
sudo vi /etc/hosts
# Add these lines (replace with your actual IPs)
192.168.1.10 k8s-master
192.168.1.11 k8s-worker1
192.168.1.12 k8s-worker2Disable Swap
Kubernetes requires swap to be disabled:
sudo swapoff -a
sudo sed -i '/ swap / s/^/#/' /etc/fstabDisable SELinux (Temporary – For Testing)
For simplicity in testing environments, disable SELinux. In production, configure proper SELinux policies:
sudo setenforce 0
sudo sed -i 's/^SELINUX=enforcing$/SELINUX=permissive/' /etc/selinux/configNote: For production, keep SELinux enabled and configure Kubernetes with proper SELinux contexts.
Step 2: Install Container Runtime (containerd)
Kubernetes requires a container runtime. We’ll use containerd, the industry-standard runtime in 2026.
Load Required Kernel Modules
cat <Configure Kernel Parameters
cat <Install containerd
sudo dnf config-manager --add-repo https://download.docker.com/linux/centos/docker-ce.repo
sudo dnf install -y containerd.ioConfigure containerd
sudo mkdir -p /etc/containerd
sudo containerd config default | sudo tee /etc/containerd/config.toml
# Enable systemd cgroup driver
sudo sed -i 's/SystemdCgroup = false/SystemdCgroup = true/' /etc/containerd/config.toml
sudo systemctl restart containerd
sudo systemctl enable containerd
sudo systemctl status containerdStep 3: Install Kubernetes Components
Install kubeadm, kubelet, and kubectl on ALL nodes.
Add Kubernetes Repository
cat <Install Kubernetes Packages
sudo dnf install -y kubelet kubeadm kubectl
sudo systemctl enable kubeletNote: Don't start kubelet yet. It will start automatically after cluster initialization.
Step 4: Configure Firewall
Open required ports on all nodes.
Master Node Firewall Rules
sudo firewall-cmd --permanent --add-port=6443/tcp # Kubernetes API server
sudo firewall-cmd --permanent --add-port=2379-2380/tcp # etcd server client API
sudo firewall-cmd --permanent --add-port=10250/tcp # Kubelet API
sudo firewall-cmd --permanent --add-port=10251/tcp # kube-scheduler
sudo firewall-cmd --permanent --add-port=10252/tcp # kube-controller-manager
sudo firewall-cmd --permanent --add-port=10255/tcp # Read-only Kubelet API
sudo firewall-cmd --reloadWorker Node Firewall Rules
sudo firewall-cmd --permanent --add-port=10250/tcp # Kubelet API
sudo firewall-cmd --permanent --add-port=30000-32767/tcp # NodePort Services
sudo firewall-cmd --reloadStep 5: Initialize Kubernetes Master Node
Run these commands ONLY on the master node.
Initialize the Cluster
sudo kubeadm init --pod-network-cidr=10.244.0.0/16 --apiserver-advertise-address=192.168.1.10Replace 192.168.1.10 with your master node's actual IP address.
This process takes 2-5 minutes. Upon completion, you'll see output containing:
- Setup commands for kubectl configuration
- kubeadm join command - Save this! You'll need it to add worker nodes
Configure kubectl Access
mkdir -p $HOME/.kube
sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
sudo chown $(id -u):$(id -g) $HOME/.kube/configVerify Master Node Status
kubectl get nodes
kubectl get pods --all-namespacesThe master node will show "NotReady" status until we install a pod network.
Step 6: Install Pod Network (Flannel)
Kubernetes needs a pod network addon for inter-pod communication. We'll use Flannel.
kubectl apply -f https://github.com/flannel-io/flannel/releases/latest/download/kube-flannel.ymlWait 1-2 minutes, then verify:
kubectl get pods -n kube-flannel
kubectl get nodesThe master node should now show "Ready" status.
Step 7: Join Worker Nodes to Cluster
On EACH worker node, run the kubeadm join command from Step 5 initialization output:
sudo kubeadm join 192.168.1.10:6443 --token abc123.xyz789token --discovery-token-ca-cert-hash sha256:longhashvalue...Lost your join command? Generate a new token on the master:
kubeadm token create --print-join-commandVerify Cluster Status
On the master node:
kubectl get nodes -o wide
# Should show:
# NAME STATUS ROLES AGE VERSION
# k8s-master Ready control-plane 10m v1.29.0
# k8s-worker1 Ready 5m v1.29.0
# k8s-worker2 Ready 5m v1.29.0 Step 8: Deploy Test Application
Let's verify the cluster works by deploying nginx.
Create Deployment
kubectl create deployment nginx --image=nginx --replicas=3Expose as Service
kubectl expose deployment nginx --port=80 --type=NodePortCheck Deployment Status
kubectl get deployments
kubectl get pods -o wide
kubectl get services
# Get the NodePort
kubectl get svc nginxAccess the Application
If the service shows NodePort as 30080:
curl http://192.168.1.11:30080 # Using worker node IPYou should see the nginx welcome page HTML.
Step 9: Install Kubernetes Dashboard (Optional)
The Kubernetes Dashboard provides a web UI for cluster management.
Deploy Dashboard
kubectl apply -f https://raw.githubusercontent.com/kubernetes/dashboard/v2.7.0/aio/deploy/recommended.yamlCreate Admin User
cat <Get Access Token
kubectl -n kubernetes-dashboard create token admin-userSave this token - you'll need it to log in to the dashboard.
Access Dashboard
kubectl proxyAccess at: http://localhost:8001/api/v1/namespaces/kubernetes-dashboard/services/https:kubernetes-dashboard:/proxy/
Paste the token from the previous step to log in.
Step 10: Monitoring and Management Tools
Install Metrics Server
Required for kubectl top commands:
kubectl apply -f https://github.com/kubernetes-sigs/metrics-server/releases/latest/download/components.yaml
# Verify
kubectl top nodes
kubectl top podsInstall Helm Package Manager
curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash
helm versionProduction Best Practices
High Availability Configuration
For production, run multiple master nodes:
- 3 or 5 master nodes (odd numbers for etcd quorum)
- Load balancer in front of API servers
- Separate etcd cluster for large deployments
Security Hardening
- Enable RBAC: Already enabled by default in Kubernetes 1.29
- Network policies: Implement pod-to-pod access controls
- Pod Security Standards: Enforce restricted pod security policies
- Certificate rotation: Automate certificate renewal
- Audit logging: Enable API server audit logs
Backup and Disaster Recovery
# Backup etcd data
sudo ETCDCTL_API=3 etcdctl snapshot save snapshot.db --endpoints=https://127.0.0.1:2379 --cacert=/etc/kubernetes/pki/etcd/ca.crt --cert=/etc/kubernetes/pki/etcd/server.crt --key=/etc/kubernetes/pki/etcd/server.keyResource Management
Set resource limits for all pods:
resources:
requests:
memory: "64Mi"
cpu: "250m"
limits:
memory: "128Mi"
cpu: "500m"Troubleshooting Common Issues
Pods Stuck in Pending State
kubectl describe pod
# Check for: Insufficient CPU/memory, node selector issues, or PVC binding problems Node NotReady Status
kubectl describe node
systemctl status kubelet
journalctl -u kubelet -f Network Issues
kubectl get pods -n kube-flannel
kubectl logs -n kube-flannel Certificate Expiration
kubeadm certs check-expiration
kubeadm certs renew allUpgrading Kubernetes on Rocky Linux 9
Always upgrade one minor version at a time (1.28 β 1.29 β 1.30).
Upgrade Master Node
# Update kubeadm
sudo dnf upgrade -y kubeadm-1.29.x
# Verify upgrade plan
kubeadm upgrade plan
# Apply upgrade
sudo kubeadm upgrade apply v1.29.x
# Upgrade kubelet and kubectl
sudo dnf upgrade -y kubelet-1.29.x kubectl-1.29.x
sudo systemctl restart kubeletUpgrade Worker Nodes
# Drain node
kubectl drain k8s-worker1 --ignore-daemonsets
# On worker node
sudo dnf upgrade -y kubeadm-1.29.x kubelet-1.29.x kubectl-1.29.x
sudo kubeadm upgrade node
sudo systemctl restart kubelet
# Uncordon node
kubectl uncordon k8s-worker1Cost Optimization for Kubernetes
- Use Rocky Linux instead of RHEL: Save $349-$1,299 per node annually
- Right-size nodes: Start with smaller instances, scale as needed
- Implement autoscaling: Cluster Autoscaler and Horizontal Pod Autoscaler
- Resource requests/limits: Prevent resource waste
- Spot/preemptible instances: For non-critical workloads
Next Steps
Now that you have a working Kubernetes cluster on Rocky Linux 9:
- Deploy real applications: Start with stateless apps before databases
- Implement CI/CD: Integrate with Jenkins, GitLab CI, or GitHub Actions
- Add persistent storage: Configure NFS, Ceph, or cloud storage classes
- Set up monitoring: Install Prometheus and Grafana
- Implement logging: Deploy EFK (Elasticsearch, Fluentd, Kibana) stack
- Service mesh: Consider Istio or Linkerd for advanced networking
Conclusion
You now have a fully functional Kubernetes cluster running on Rocky Linux 9! This setup provides an enterprise-grade container orchestration platform with the stability of RHEL-compatible systems and zero licensing costs.
Rocky Linux 9's 10-year support lifecycle ensures your Kubernetes infrastructure remains stable and secure for years to come. Whether you're running development workloads or production applications, this foundation gives you the flexibility and reliability needed for modern cloud-native deployments.
What's your next Kubernetes project? Share your experiences deploying Kubernetes on Rocky Linux in the comments below!
Was this article helpful?
About Ramesh Sundararamaiah
Red Hat Certified Architect
Expert in Linux system administration, DevOps automation, and cloud infrastructure. Specializing in Red Hat Enterprise Linux, CentOS, Ubuntu, Docker, Ansible, and enterprise IT solutions.
